Display Technology |
Single 0.65” WXGA DC3 DMD chip DLP® Technology by Texas Instruments |
Native Resolution |
WXGA 1280 x 800 |
Brightness1 (Bright Mode) |
3400 ANSI Lumens |
Contrast |
20,000:1 |
Noise Level (Eco mode) |
29dB |
Weight (kg) |
2.55 |
I/O Connectors |
HDMI (1.4a 3D support), 2 x VGA (RGB/YPbPr/Wireless), S-Video, Composite, Audio In 3.5mm, Audio Out 3.5mm, VGA Out, RS232, USB (Remote Mouse) |
Preset Mode |
Movie: Maximum contrast and Colour accuracy sRGB: Best Colour Reproductiion User: Memorises user's settings Presentation Default mode, perfect with computers or notebooks Bright For environments with high ambient light (Brighest image) Blackboard Perfect for installations with blackboards |
Maximum Resolution |
UXGA 1600 x 1200 |
Computer Compatibility |
UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac |
Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p) |
Projection Lens |
F/2.8; f=7.017mm, Fixed Zoom |
Throw Ratio |
0.52:1 |
Projection Screen Size |
1.13 - 5.67m (44.64" - 223.21") Diagonal 16:10 |
Projection Distance |
0.5 - 2.5m |
Zoom Type |
Fixed |
Aspect Ratio |
16:10 Native, 4:3/16:9 Compatible |
Offset |
115% ±5% |
Horizontal Scan Rate |
15 - 91kHz |
Vertical Scan Rate |
25 - 85Hz (120Hz for 3D) |
Lamp Type |
190W |
Lamp Life (Eco/Bright Mode) |
6,000/4.500 |
Keystone Correction |
± 40° Vertical |
Dimensions (W x D x H) |
288 x 220 x 86 |
Remote Control |
Full function remote with laser pointer, mouse control and direct source selecting |
Power Supply |
100-240V, 50-60Hz |
Power Consumption |
235W BRIGHT mode < 0.5W Standby mode, 205W Eco+ mode < 0.5W Standby mode |
Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
Uniformity |
80% |
Security |
Security Bar, Kensington Lock, Password Protection |
Standard Accessories |
Lens Cover, AC Power Cord, Infra Red Remote Control with Batteries, Quick Start Card, CD User Manual, Warranty Card |
Optional Accessories |
Wall Mount - OWM855W |
RoHS |
Compliant |
3D Support |
The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification. |
3D Compatibility |
Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60 |
3D Viewing |
Requires Optoma ZD301 DLP® LinkTM active shutter glasses – sold separately |
Speaker |
2 Watts |
Warranty |
2 Years |
On Screen Display |
19 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek, Norwegian/Danish, Hungarian, Czech, Turkish, Romanian, Farsi, Arabic |
Optional Wireless |
No |
Features |
Gaming even in the smallest of rooms |
1Brightness and lifetime will vary depending on selected projector mode, environmental conditions and usage. As is common with all projectors, brightness will decrease over the lifetime
2Typical lamp life achieved through testing. Will vary according to operational use and environmental conditions |
